MCE 0.45μm Cartridge Filters
Product Introduction
Alioth Aligard® MHF Single-layer Cartridge Filter is made from mixed cellulose ester. It has a nominal filtration accuracy of 0.2 μm, a sturdy structure and stable material. It can efficiently retain pollutants, effectively remove particles and colloidal contaminants, block no important active ingredients, protect downstream filtration equipment, and prevent premature clogging.
Alioth Aligard® MHF Single-layer Cartridge Filter is made from mixed cellulose ester. It has a nominal filtration accuracy of 0.2 μm, a sturdy structure and stable material. It can efficiently retain pollutants, effectively remove particles and colloidal contaminants, block no important active ingredients, protect downstream filtration equipment, and prevent premature clogging.
-
-
-
Product Specifications
10 inch 20 inch 30 inch Dimensions
Diameter
Maximum Length69 mm
320 mm69 mm
560 mm69 mm
800 mmFiltration Area 0.68 m2 1.32 m2 1.98 m2 Pore Size 0.2 μm Materials of Construction Filter membrane:Mixed Cellulose Ester
Supporting Layer: Polypropylene (PP)
O-rings of capsules vent: SiliconeLiner / Cartridge body: Polypropylene (PP)
End caps: Polypropylene/ Polycarbonate (PP/PC)Maximum Differential
PressureForward: 5 bar ( 72.5 psi ) @ 25℃ / 1.5 bar ( 21.75 psi ) @ 80℃ / Reverse: 2 bar ( 29 psi ) @ 25℃ Sterilization Parameters 121℃, 30 minutes, 5 cycles of high-pressure sterilizations or 5 cycles of sterilization in place Extractable Water: ~20 mg / 10 inch
Ethanol: water ( 50:50 ): ~55 mg / 10 inchBiological Safety All the construction components of this cartridge comply with the requirements for biological safety of Class VI plastics in current USP < 88 > Indirect Food Additive The primary construction components of this cartridge comply with the reguirements for food contact materials as stipulated in EU 1935 / 2004 / EC and FDA 21 CFR 177-182 Cleanliness Cleanliness meets the requirements for nonfiber releasing filter as specified in FDA 21 CFR 211.72 and 210.3 (b) (5) (6), and the level of insoluble particles in rinsing liquid meets the
requirements of USP < 788 >Endotoxin The endotoxin level of cartridge rinsing liquid is < 0.25 EU/mL as indicated by gel method, which complies with the requirements of USP < 85 > Integrity Each filter has passed the integrity test TOC / Conductivity TOC < 0.5 mg/L, Conductivity < 1.3 μS/cm Manufacturing environment Manufactured in conformance with cGMP Test Results of Flow Differential Pressure
