PTFE 0.2μm Sterilizing-Grade Cartridge Filters

Data Download：

The Alioth Alipore® TAHF series features a hydrophobic and chemically inert PTFE (polytetrafluoroethylene) filter membrane. This product efficiently retains microorganisms and particles in wet or humid gas through stringent liquid bacteria retention verification. It offers high strength and resistance to multiple steam sterilizations in place. The TAHF series is suitable for sterile gas filtration and organic solvent filtration with strict quality requirements in pharmaceutical applications.
Depth Stacked DataSheet
넳 넲

  • 我是段落。点击这儿添加你的文字并编辑它，非常容易。-双击进行编辑



    • Natural hydrophobic material.

    • High gas flux and low-pressure drop.

    • Reliable bacterial retention and particles removal ability.

    • Excellent chemical compatibility.



  •

    • Sterile gas filtration

    • VentSterile filtration of most organic solvents





  • Product Specifications—Cartridge Filter

      5inch 10inch 20inch 30inch

    Dimensions



    Diameter
    Maximum Length



    69 mm
    150 mm



    69 mm
    320 mm



    69 mm
    560 mm



    69 mm
    800 mm
    Filtration Area 0.35 m2 0.7 m2 1.4 m2 2.1 m2
    Pore Size 0.2 μm
    Materials of
    Construction

    Filter membrane: Polytetrafluoroethylene (PTFE)

    Supporting Layer: Polypropylene (PP)
    O-rings of capsules vent: Silicone

    Liner / Cartridge body: Polypropylene (PP)
    End caps: Polypropylene/ Polycarbonate (PP/PC)
    Bacterial Retention ＞107 cfu/cm2 B. diminuta ( ATCC® 19146TM）
    Maximum

    Differential

     Differential    		 Forward: 5.0 bar（72.5 psi）@ 25°C / 3.0 bar（43.5 psi）@ 80°C
    Reverse: 2.0 bar（29.0 psi）@ 25℃
    Bubble Point ≥1200 mbar（17.4 psi）(wetted with 60% IPA, 20℃, compressed air)
    Diffusion Through a 60% IPA wet membrane at 1040 mbar (15 psi) （20℃, compressed air ）
    ≤6.5 mL/min ≤ 13 mL/min ≤ 26 mL/min ≤ 39 mL/min
    Water Intrusion at 2500 mbar (36 psi) （20℃, compressed air ）
    ≤ 0.25 mL/min ≤ 0.5 mL/min ≤ 1.0 mL/min ≤ 1.5 mL/min
    Sterilization Steam in place: 135℃, 60 min, 25 cycles
    Autoclave: 135℃, 60 min, 25 cycles
    Biological Safety All the construction components of this filter comply with the requirements for biological safety of Class VI plastics in current USP<88>
    Indirect Food Additive The primary construction components of this filter comply with the requirements for food
    contact materials as stipulated in EU 1935 / 2004 / EC and FDA 21 CFR 177-182
    Cleanliness Cleanliness meets the requirements for nonfiber releasing filter as specified inFDA21 CFR211.72 and 210.3 (b) (5) (6), and the level of insoluble particles in rinsing liquid meets the requirements of USP< 788>
    Endotoxin The endotoxin level of cartridge rinsing liquid is <0.25 EU/mL as indicated by gel method, which complies with the requirements of USP<85>
    Integrity 100% has passed the integrity test
    Manufacturing Environment

    Manufactured in conformance with cGMP



    Test Results of Flow Differential Pressure

    Air Flow Rate and Pressure Drop -Alipore® TAHF 0.2μm Cartridge Filters                      Air Flow Rate and Pressure Drop -Alipore® TAHF 0.2μm Alicap L300 Capsule Filters

                                                                                                                                                                                              （KFBTA02S2B6S1A）
