Disposable Vacuum Filtration Device

Data Download：

High Retention,Low Adsorption,Easy Operation,Gamma Sterilization

넳 넲

我是段落。点击这儿添加你的文字并编辑它，非常容易。-双击进行编辑

• Available in 4 sizes: 150 mL / 250 mL / 500 mL / 1000 mL, which can meet the requirements for handling different volumes of samples.

• Utilize the latest generation of highly asymmetric pharmaceutical-grade polyethersulfone (PES) sterilizing membrane.

• Low adsorption, high flow rate, and high capacity.

• Thick bottle wall and low center of gravity, thus improving the stability of filtration device.

• The screw cap, hose connection, and other parts are ergonomically designed, enabling easy and effortless operation.

• The scales are accurate and easy to read.

• Individually packaged and subjected to gamma irradiation sterilization.

• Free from DNAse, RNAse, and pyrogen.
• Cell culture media filtration

• Buffer solution filtration

• Protein intermediate filtration

• Filtration of other biological samples and reagents

Product Characteristics

Volume ( mL )	Filter membrane diameter ( mm )	Working volume ( mL )	Residual volume ( mL )	Maximum operating temperature ( ℃ )
150	50	150	3	45
250	50	250	3	45
500	75	500	3	45
1000	91	1000	3	45

Product Characteristics

Upper cup and collection bottle: Polystyrene
Vacuum port connector: ABS
Bottle cap: Polyethylene
Membrane material: Polyethersulfone ( PES )
All the materials above comply with USP standards for Class VI plastics

Maximum Operating Pressure

0.09 Mpa

Filtration Performance Comparison

Alioth BrilliFlow^® Disposable Vacuum Filtration Device exhibits superior overall performance in filtering high-, medium-, and low-turbidity materials, with a small residual volume

Filtration Performance Comparison

Parameters	Alioth ( 500 mL )	Competitor A ( 500 mL )	Competitor B ( 500 mL )
Membrane material	PES	PES	PES
Diameter ( mm )	75	65	73
Area ( cm²)	44.2	33.2	40
Measured retention volume ( mL )	3.21	1.97	4.7
