Membrane Filters

Data Download：

Product Introduction
Alioth Membrane Filter is made from hydrophilic polyethersulfone (PES) membrane, and placed in a compatible membrane holder. It can remove particles and microorganisms from liquids, thus very suitable for the development and validation of early-stage filtration process. Besides, it can withstand multiple cycles of high-temperature and high-pressure sterilization, meeting the common requirements for liquid filtration in pharmaceutical industry.
Depth Stacked DataSheet
넳 넲

  • 我是段落。点击这儿添加你的文字并编辑它，非常容易。-双击进行编辑



    • Good chemical compatibility,Good wettability,Good optical properties.

    • High retention capacity.

    • Low adsorption.

    • Appropriate flow rate.

    • Few extractables.

    • Can withstand multiple cycles of moist heat sterilization.

    • Can withstand gamma irradiation sterilization.

    • Original membrane integrity tested.

    • Stable performance, sturdy structure and durable service.

    • Available pore sizes: 0.45 μm, 0.2 μm.

    • Available diameters: 47 mm, 90 mm, 142 mm, 200 mm.

    • Easy and flexible operation, user-friendly.



  •





  • Product Specifications

    Conductivity PES material PES material PES material PES material
    Diameter (mm) 47 mm 90 mm 142 mm 200 mm
    Effective filtration area (cm2) 13 cm2 50 cm2 141 cm2 255 cm2
    Thickness (μm) Approximately 110 μm
    Pore size Available in 0.45 μm, 0.2 μm
    Maximum operating temperature Can withstand moist heat sterilization
    Integrity As an example, for PES A series with a single layer of 0.2 μm, bubble point is 4.8 ± 0.5 bar
    As an example, for PES C series with a single layer of 0.2 μm, bubble point is 4.3 ± 0.5 bar
    Water flux As an example, for PES A series with a single layer of 0.2 μm, water flux is ≥ 45 mL / bar/min / cm2
    As an example, for PES C series with a single layer of 0.2 μm, water flux is ≥ 35 m L/ bar/min / cm2
    Bacterial retention capacity The diaphragm passed the retention test using 107 CFU / cm2 defective Pseudomonas aeruginosa ( ATCC® 19146TM ) according to the ASTM test method.
    Biological safety Meet the biological safety requirements for Class VI plastic materials in USP < 88 >
    Quality system Production follows a quality management system recognized by the ISO 9001 quality system standard certification body
    Production system Class 100,000 clean workshop
    Shelf life 3 years at 10-35°C and below 70% humidity
