Stainless Steel Filter Housing

Data Download:

Alioth Stainless Steel Filter Housing is designed according to sanitary requirements and GMP requirements. Combined with various materials of diaphragms and various sizes of cartridge filters produced by Alioth, it can be flexibly used at different stages of different processes in different industries. It is extremely easy to clean and drain, poses no concerns about residual liquid, and can meet the strict requirements of key material liquid and key parts for filter housing in biopharmaceutical.
Depth Stacked DataSheet
  • 我是段落。点击这儿添加你的文字并编辑它,非常容易。-双击进行编辑



    • Sanitary design, which meets the strict regulatory requirements of pharmaceutical industry.

    • Compliant with cGMP standards.

    • Effort-saving, safe and easy operation.

    • Compatible with major brands of cartridge filters in the market.

    • Equipped with a low-point drain valve for easy removal of residual material liquid and CIP liquid.

    • Equipped with a high-point vent valve to prevent filtration blockage caused by compressed gas and ensure SIP performance.

    • Available in a full range of specifications for laboratory research scale, clinical pilot production scale, and commercial large-scale production.

    • Adopt industry-standard chuck interface connection.

    • Can be specially customized according to the requirements of customer.





  •

    • Culture media filtration

    • Collection of fermentation broth

    • Water for injection

    • Gas filtration



  • Product Characteristics

    Material Filter housing: 316 L stainless steel
    Gasket: Silicone rubber
    Hoop: 304 stainless steel
    Filter connector type Code 7 / 2-226
    Sterilization Available for steam sterilization in place or
    high-pressure moist heat sterilization
    Finish Internal polishing ≤ 0.6 μm; external polishing ≤ 0.8 μm
    Size of loadable filter 5 inch /10 inch /20 inch /30 inch
    Size/weight Please refer to the drawings of products with different article numbers for details
    Number of loadable filters 1 cartridge, 3 cartridges, 5 cartridges, 7 cartridges, 9 cartridges, 11 cartridges ※ ( please
    contact sales personnel for customization )
    Maximum operating conditions 25°C @10 bar;145°C @3.2 bar



    Product Documentation Package

    • Basic drawings of the product
    • Maintenance guide and operation manual
    • Calibration certificates of instruments
    • Material certification documents
    • Certification document of surface finish
    • List of spare parts
    • Custom files related to other customized products



    Information on Spare Parts
