Stainless Steel Depth Filter Holder M Type
Alioth Stainless Steel Depth Filter Holder M Type is commonly used to hold depth filter holder of a specific area. With the help of a specific power source, it allows material liquid to pass through the depth filter, thus achieving the purpose of separating impurities from liquid. When used in combination with Alioth-produced depth filter, it can support the needs for different scales of production and use. Made from 316L stainless steel, it meets the requirements of pharmaceutical industry.
-
-
-
Product Specifications
Type 2.2 m2 5.5 m2 11 m2 22 m2 33 m2 Dimension (length × width
× height) cm81x 64 x51 cm
103x64x51 cm(including
pipeline valves)133x73x100 cm
162x73x100 cm(including
pipeline valves)196x73x100 cm
223x73x100 cm(including
pipeline valves)199x89x117 cm
203x89x117 cm(including
pipeline valves)195x89x157 cm
203x89x177 cm(including
pipeline valves)Weight (kg) 110-120 kg 160-170 kg 180-190 kg 340-360 kg 480-500 kg Holder baffle SS 304 Liquid-contacting part SS 316 L Surface finish Surface finish Ra < 1.2 μm, liquid-contacting surface finish Ra < 0.6 μm Equipment frame SS 304 Product Documentation Package
- COQ
- Basic drawings of the product
- Maintenance guide and operation manual
- Calibration certificates of instruments
- Material certification documents
- Certification document of surface finish
- FDA certificate for hydraulic oil
- Seal component 2.2 certificate
- EN 10204 certificate for flow passage component
- IQ/OQ validation service and documents
- List of spare parts
- Custom files related to other customized products
Product Configuration
- Alioth depth cartridge filter is connected to process pipelines through disposable connectors, forming disposable flow passage
- Disposable separation plate allows installation of more than one filter models on a single-layer holder
Ordering Information
Order No. Product description Package
QuantityDFHBGM 2 A 2-1 Depth Filter Holder M Type 2.2 m2, with liquid-contacting tray at the bottom 1 / PK DFHBGM 2 A 2-2 Depth Filter Holder M Type 2.2 m2, with liquid-contacting tray at the bottom, and valve pressure gauge 1 / PK DFHBGM 2 A 2-ET 31 Depth Filter Holder M Type 2.2 m2, with extension rod for holding 5.5 m2, and liquid-contacting tray at the bottom 1 / PK DFHBGM 2 A 2-ET 32 Depth Filter Holder M Type 2.2 m2, with extension rod for holding 5.5 m2, liquid-contacting tray at the bottom, and valve pressure gauge 1 / PK DFHBGM 5 A 5-1 Depth Filter Holder M Type 5.5 m2, with liquid collection tray at the bottom 1 / PK DFHBGM 5 A 5-2 Depth Filter Holder M Type 5.5 m2, with liquid-contacting tray at the bottom, and valve pressure
gauge1 / PK DFHBGM11 A-1 Depth Filter Holder M Type 11 m2, with liquid-contacting tray at the bottom 1 / PK DFHBGM11 A-2 Depth Filter Holder M Type 11 m2, with liquid-contacting tray at the bottom, and valve pressure gauge 1 / PK DFHBGM 22 A-1 Depth Filter Holder M Type 22 m2, with liquid-contacting tray at the bottom, and U-shaped connector 1 / PK DFHBGM 22 A-2 Depth Filter Holder M Type 22 m2, with liquid-contacting tray at the bottom, U-shaped connector, and valve pressure gauge 1 / PK DFHBGM 22 A-3 Depth Filter Holder M Type 22 m2, with liquid collection trays at the bottom and top, and U-shaped connector 1 / PK DFHBGM 22 A-4 Depth Filter Holder M Type 22 m2, with liquid-contacting trays at the bottom and top, U-shaped
connector, and valve pressure gauge1 / PK DFHBGM 33 A-1 Depth Filter Holder M Type 33 m2, with liquid-contacting tray at the bottom, and T-shaped connector 1 / PK DFHBGM 33 A-2 Depth Filter Holder M Type 33 m2, with liquid-contacting tray at the bottom, T-shaped connector, and valve pressure gauge 1 / PK DFHBGM 33 A-3 Depth Filter Holder M Type 33 m2, with liquid-contacting trays at the bottom and middle part, and T-shaped connector 1 / PK DFHBGM 33 A-4 Depth Filter Holder M Type 33 m2, with liquid-contacting trays at the bottom and middle part,
T-shaped connector, and valve pressure gauge1 / PK DFHBGM 33 A-5 Depth Filter Holder M Type 33 m2, with liquid-contacting trays at the bottom, middle part and top, and T-shaped connector 1 / PK DFHBGM 33 A-6 Depth Filter Holder M Type 33 m2, with liquid-contacting trays at the bottom, middle part and top, T-shaped connector, and valve pressure gauge 1 / PK
