Stainless Steel Depth Filter Holder P Type

Data Download：

Alioth Stainless Steel Depth Filter Holder P Type is commonly used in deep depth filtration process. It is used to clamp depth filter holder of a specific area. With the help of a specific power source, it allows liquid to pass through the deep depth filter, thus achieving the purpose of separating impurities such as solid particles from liquid.
Made from 316 L stainless steel, it is compatible with different types of liquids and meets the special requirements of pharmaceutical industry.
Depth Stacked DataSheet
넳 넲

  • 我是段落。点击这儿添加你的文字并编辑它，非常容易。-双击进行编辑



    • Vertical design; with guide plates, allow for filtration operations such as bottom-in and bottom-out, top-in and bottom-out, and bottom-in and top-out.

    • Made from 316 L stainless steel.

    • Surface finish Ra < 1.2 μm.

    • Diaphragm valves and pressure gauges, which meet cGMP's requirements for designing sanitary dead angle in the structure conforming to pharmaceutical-grade standards.

    • Optionally equipped with hydraulic device and filter holder; effort-saving, safe and easy operation.

    • Compatible with major brands of round cake-type depth filter holders in the market.

    • Comprehensive range of product specifications, and flexible selection.

    • Resistant to acid, alkali, organic solvents, etc., and meeting SIP/CIP as well as cleaning validation requirements.

    • Adopt industry-standard chuck interface connection.

    • Can be specially customized according to the requirements of customer .



  •

    • Clarification step in monoclonal antibody production process

    • Clarification step in recombinant protein production process

    • Clarification step in vaccine production process

    • Clarification step in blood product production process

    • Clarification step in cellular/genetic drug production process

    • Alioth Hardware Series



  • Product Specifications

    Type Hydraulic filter holder Manual filter holder
    Dimension (length × width × height) cm

    115 x 94 x 223 cm

    (10 m2 filter holder,
    with a large baseplate)

    115 x 82 x 156 cm

    (5 m2 filter holder,
    with a large baseplate)

    115 x 94 x 223 cm

    (10 m2 filter holder,
    with a large baseplate)

    115 x 82 x 156 cm

    (5 m2 filter holder,
    with a large baseplate)
    Weight (kg) 170-180 kg 170-180 kg
    Surface finish Surface finish Ra < 1.2 μm, liquid-contacting surface finish Ra < 0.6 μm
    Equipment frame SS 304



    Product Documentation Package

    • COQ
    • Basic drawings of the product
    • Maintenance guide and operation manual
    • Calibration certificates of instruments
    • Material certification documents
    • FDA certificate for hydraulic oil
    • Certification document of surface finish
    • IQ/OQ validation service and documents
    • List of spare parts
    • Custom files related to other customized products
